X,Y,R axis manipulator, accurate positioning, repeated accuracy ±0.05.
Can rotate 360 degrees custom equal length attach tape.
Customizable adhesive length.
Tape out of material alarm.
The tray can be quickly replaced and positioned.
Internal material detection, inconsistent with the set procedure alarm.
| Operating System | PLC&WIN Control |
| Operation Interface | Human-machine Screen&HIMI |
| Control Mode | Bus Control |
| Movement Precision | ±0.1 mm |
| UPH | 12S/PCS(4 equal parts) |
| Transmission Speed | |
| Positioning Accuracy | ±0.05mm |
| Transport Height | |
| External Dimension | 800*800*850mm |
| Weight | 80KG |
| Input Power | AC 220V |
| Air Pressure | 0.4-0.8MPa |
